Enterprise SATA-III SSD
Storage Capacity
-
Tel.+86 27 65320000
-
E-mail:YMTC@ymtc.com
Broad Compatibility
SE006 has been validated with more than 34 major server platforms and over 18 mainstream RAID Controller Cards, enabling seamless migration and rapid deployment with less hardware modification cost increase.
Advanced Technology, Constantly Supply
SE006 is built with YMTC's latest generation X4-9070 3D NAND based on Xtacking®4.0 technology, providing customers with advanced technology and constantly supply.
High Reliability
SE006 features Power Loss Protection, validated by more than 7,000 abnormal power-cycle tests. It incorporates industry-leading thermal design, which ensures stable SSD operations under high temperature. The mean time between failures (MTBF) of SE006 is 2 million hours, ensuring data security and reliability.
High Performance
SE006 delivers high performance with sequential read/write speeds of up to 560MB/s and 530MB/s, and random read/write IOPS of up to 97K and 40K. Compared with SE005* (the previous generation SATA SSD), SE006 achieves a 10% lower read latency, providing faster system response and high-efficient services.
Flexible Options
SE006 is available in 480GB/960GB/1.92TB/3.84TB/7.68TB, suitable for diverse workload requirements.
| Model | SE006 | ||||
| Dimensions | 2.5"7mm | ||||
| Interface | SATA III | ||||
| Capacity | 480GB | 960GB | 1920GB | 3840GB | 7680GB |
| Sequential Read (MB/s) | 560 | 560 | 560 | 560 | 560 |
| Sequential Write (MB/s) | 525 | 530 | 530 | 530 | 530 |
| Random Read 4K (IOPS) (K) | 62 | 97 | 97 | 97 | 97 |
| Random Write 4K (IOPS) (K) | 31 | 40 | 37 | 37 | 35 |
| 70%R/30%W(IOPS) (K) | 46 | 60 | 59 | 59 | 56 |
Random Read Latency (us) | 110 | ||||
Random Write Latency (us) | 40 | ||||
| Idle (W) | <1.3 | ||||
| Operating (W) | <4 | ||||
| UBER | <10^-17 | ||||
| MTBF(H) | 2.0 Million | ||||
| Warranty | 5 Years | ||||
| Dimensions & Weight | 6.9mm x 69.85mm x 100mm ,<72g | ||||
| Vibration Rating | 3.13 GRMS, 5-800Hz (Non-operation) | ||||
| Shock Rating | 1,000G@0.5ms(Operation); 1,500G@0.5ms (Non-operation) | ||||
| Operating Temperatures | 0°C to 70°C | ||||
| Features | Thermal Throttle, TRIM, RAID, SMART, Power Management | ||||
| Certifications | SATA-IO, RoHS(China), BSMI, WEEE, RoHS(EU) , CE, FCC, Halogen Free, UL | ||||
1. SE005 is YMTC’s first generation SATA III enterprise SSD.
2. The above performance is verified with YMTC’s internal test platform. Actual results may vary among different host devices and testing conditions.
3. 1MB = 1000KB, 1GB = 1000MB, 1TB = 1000GB. Total accessible capacity on storage devices may also vary depending on operating environment.
4. All product images on this website are for display purposes only. Actual products may differ, please refer to the physical product for the most accurate information.
5. YMTC reserves the right to change product images, descriptions, and specifications without prior notice.
